DARWIN-S430CZ200020M

16x25Gb SFP28, 4x100Gb QSFP28 L3 Aggregation/Leaf Switch,  Enterprise SONiC Ready, MLAG VXLAN

The DARWIN-S430CZ200020M is a 16×25G aggregation switch with 4×100G QSFP28 uplinks, built for campus aggregation, spine applications, enterprise networks, and cloud service provider deployments. Powered by the Marvell Aldrin 3 chipset in a compact 1RU form factor, it delivers high throughput, port density, and efficiency in a sleek design.

Running on AsterNOS, the commercial SONiC-based NOS, this Layer 3 switch offers a comprehensive feature set—from industry-standard routing protocols like OSPF and BGP to advanced capabilities including VXLAN, BGP-EVPN, MLAG, and IPv6. Optional PTP and MPLS support further enable low-latency, time-sensitive, and high-performance workloads.

In modern network architectures, the DARWIN-S430CZ200020M typically serves as a distribution/aggregation switch, but in small to mid-sized networks, it can also function as a cost-effective Top-of-Rack (ToR)/Leaf switch, providing a versatile solution for private clouds or compact data centers.

Layer 3 Features

• IPv4/v6 Dual Stack
• Policy Based Routing
• Resilient ECMP
• ARP-to-Host
• VRF
• Bi-Directional Forwarding Detection (BFD)
• IGMP v2/v3
• Route Map
• VRRP
• GRE
• Routing Protocols: OSPF v2/v3, BGP, MP-BGP

Virtualization Features

• VXLAN Centralized/Distributed Gateway
• EVPN Type 2/3/5

    Quality of Service (QoS)

• 8 Queues per Port
• 802.1p Based Classification
• DSCP Based Classification
• Strict priority queueing
• DWRR Scheduling
• Policing/Shaping
• Rate Limiting

Management and Monitoring

• Asteria Campus Controller
• Industry Standard CLI
• Zero Touch Provisioning (ZTP)
• SNMP v1/v2/v3
• sFlow
• Port Mirroring
• Syslog
• Log Management
• PTP IEEE 1588v2 (TC and BC)
• Containerized Custom Tools
• BGP/BFD Operational Status
