DARWIN-S047PС100802M

8×2.5G RJ45 POE++ @150W L3 Ethernet Switch, 2x10Gb SFP+ Uplinks, Enterprise SONiC Ready, Marvell AlleyCat 5Y

The 8-port 2.5G POE++ switch, DARWIN-S047PС100802M, has 8x 2.5G BASE-T ports and 2x10G SFP+ ports. It supports a maximum of 8-port PoE++ (802.3bt) for powering attached IP phones, wireless access points, or other standards-compliant PoE and PoE+ end network devices. Benefited from commercial SONiC NOS-AsterNOS, it supports rich layer 2 and layer 3 functions, including routing functions like OSPF and BGP, and other features like MLAG and IPV6 functions. This access switch offers a compact and cost-effective solution for campus networks, SMBs, and enterprise networks.

Layer 2 Features

• 4K VLANs / Voice VLAN
• Multiple Spanning Tree Protocol
• QinQ
• Link Aggregation Control Protocol
• MLAG / VLAN Trunking
• Link Layer Discovery Protocol (LLDP)
• LLDP Enhancements for PoE
• Port Isolation
• IGMP Snooping
• BPDU Guard, BPDU Filter
• Loopback Detection

Layer 3 Features

• IPv4/v6 Dual Stack
• Policy Based Routing
• Resilient ECMP
• ARP-to-Host
• VRF
• Bi-Directional Forwarding Detection (BFD)
• IGMP v2/v3
• Route Map
• VRRP
• GRE
• Routing Protocols: OSPF v2/v3, BGP, MP-BGP

Management and Monitoring

• Asteria Campus Controller
• Industry Standard CLI
• Zero Touch Provisioning (ZTP)
• SNMP v1/v2/v3
• sFlow
• Port Mirroring
• Syslog
• Log Management
• PTP IEEE 1588v2 (TC and BC)
• Containerized Custom Tools
• BGP/BFD Operational Status
